Vibratory Roller FYL203H FURD
Walk Speed 0 – 8 km/h Gradeability 20 % Drive Type Mechanical Drive – Gearbox Vibration Control Electro Hydraulic Pump Vibration Frequency 50 Hz Exiting Force 32 kN Water Tank 200 Liters Hydraulic Tank 20 Liters Engine Model Diesel Changchai ZN390B Engine Power 26.5 Kw @2200rpm Starting Methode Electric Start Front Wheel Size ø 700 * 1090 mm Back Wheel Size ø 700 * 1090 mm Overall Dimension 2830 * 1290 * 2650 mm Overall Weight 3000 Kg Standards Compliance CE/ISO Vibratory Roller FYL-D203 FURD
Walk Speed 0 – 12 km/h Gradeability 30 % Drive Type Hydraulic Transmission Vibration Control Electro Hydraulic Pump Vibration Frequency 50 Hz Exiting Force 2 * 30 kN / 30 kN Water Tank 200 Liters Hydraulic Tank 80 Liters Engine Model Diesel Changchai ZN390B Engine Power 26.5 Kw @2200rpm Starting Methode Electric Start Front Wheel Size ø 700 * 1250 mm Back Wheel Size ø 700 * 1250 mm Overall Dimension 2760 * 1400 * 2580 mm Overall Weight 3000 ~ 3400 Kg Standards Compliance CE/ISO
Telescopic Boomlift Sinoboom GTBZ26
Platform height max 25.8 Meter Working Height Max 27.8 Meter Horizontal Reach Max. 22 Meter Ground Clearance 0.41 Meter Platform Size (L*W*H) 1.45 m* 0.85m* 1.24m Max. Platform Operator 2 Lift Capacity 250 ~ 480 Kg Turntable rotation 360° Platform rotation 160° Drive Speed 0~5.2 km/h Gradeability 30% Max. Noise on Normal Use 82 dB(A) Engine Brand Cummins Engine Power 60 Kw Overall Weight 16442 Kg Standards Compliance CE/ISO/ADR/ARAMCO Stamper Dynamic DTR85H Honda GX160
Engine Model : Honda GX160
Power (hp) : 5.5
Fuel Tank (l) : 2.0
Impact Force (kN) : 10
Impact Number : 450 – 650/min
Jumping Stroke (mm) : 40 – 60
Shoe Size (mm) : 330 X 290
Weight (kg) : 79
Dimension (mm) : 1080 X 420 X 760 Steel Bar Cutter Everyday GQ46
Cutting Capacity (mm) : 6-42
Motor Power : 3.0KW-2P
Motor Speed (R/Min) : 2860
Cutting Speed (Cut/min) 48
Dimension (mm) 1100 X 500 X 900
Weight (kg) 470Jack Hammer BH23 / BH55 Wacker Neuson
Engine Model : WM80 2-Stroke
Power (hp) : 2.18
Fuel Tank (l) : 1.8/
Displacement (cc) : 80
Impact Frequency (impact/min) : 1300
Impact Energy (J) : 55
Rotation Speed (rpm) : 4250
Weight (kg) : 24
Dimension (mm) : 777 x 492 x 346High Frequency Internal Vibrator HBM40VFLH Exen
Input 250W 48V 5,5A Frequency 200 Hz Total Length shaft + box +spear 4000 + 6000mm Diameter x Length 43 mm×360mm Weight 13,9 kg -
Steel Bar Cutter Everyday GQ46
Cutting Capacity (mm) : 6-42
Motor Power : 3.0KW-2P
Motor Speed (R/Min) : 2860
Cutting Speed (Cut/min) 48
Dimension (mm) 1100 X 500 X 900
Weight (kg) 470 Bar Bender Hirano Takeda SB42
Bending Capacity Hi-Gear ⌀32mm Low-Gear ⌀41mm Speed 50Hz Hi-Gear 6.6 / Low-Gear 3.3
60 Hz Hi-Gear 8 / Low-Gear 4Motor 2,2 Kw 3~ Working Height 778mm Dimension 920 x 1070 x 990 Weight 720kg Fulcrum Diameter 55mm Bar Cutter Hirano Takeda BC41A
Cutting Capacity Hi-Gear ⌀32mm Low-Gear ⌀41mm Speed 50Hz Hi-Gear 6.6 / Low-Gear 3.3
60 Hz Hi-Gear 8 / Low-Gear 4Motor 2,2 Kw 3~ Working Height 778mm Dimension 920 x 1070 x 990 Weight 720kg Fulcrum Diameter 55mm Mechanical Converter A-Vibrass MC25
Outlets : 2
Engine : Honda GX160, 5,5HP Gasoline Engine /Diesel D168F
Output Voltage / Frequency : 42 V, 3 ~, 200 Hz
Output Power : 1.6 kVA, 30 A
Weight (kg) : 36Compatible Internal Vibrator
ENAR AFP Series
A-Vibrass Divo Series Mechanical Converter ENAR AFGH2000
Outlets : 2
Engine : Honda GX160, 5,5HP Gasoline Engine
Output Voltage / Frequency : 42 V, 3 ~, 200 Hz
Output Power : 1.6 kVA, 30 A
Weight (kg) : 36
Univ UDS-185S Air Compressor
Type Rotary Twin Screw,Free air delivery (m3/min) 5.2Rated operating pressure(kgf/cm2)(kpa) 8Air outlet valve 3/4″× 2Engine ModelISUZU 4JB1-i Natural IntakeType Direct-InjectionFuel Consumption (L/h) 6.5Fuel tank capacity (L) 80Electric StartDimension & WeightL×W×H (mm)2000×950×1060Dry (Operating) weight (kg) 1100Tire Size175R13-8PR×2WSound power level in decibels (dB)98Sound pressure level (dB[A])69Designated emissions regulation Tier 3 Airman PDS-185S-6C2 Air Compressor
Type Rotary Twin Screw, Single-Stage, Oil-cooledFree air delivery (m3/min) 5.2Rated operating pressure (MPa)[kgf/cm2][psi] 0.69[7.0][100]Compressor capacity (L) 15Air outlet valve 3/4″×2Engine ModelYANMAR 4TNV88-BXDHKSType Direct-InjectionRated output (kW/min-1)[PS/rpm] 36.4/3000[49.5/3000]Total displacement (L) 7.4Fuel tank capacity (L) 90Battery 80D26R×1Dimension & WeightL×W×H (mm)2960×1650×1510Dry (Operating) weight (kg)860(960)Tire Size175R13-8PR×2WSound power level in decibels (dB)98Sound pressure level (dB[A])69Designated emissions regulation Tier 3-
Asphalt Crack Sealing Machine FGF-60
Engine Model : Yamaha ET 950
Power : 760 W, 1 hp
Walking Mode : Hand Push
Material Tank Volume (l) : 60
Fuel Type : Liqufied Gas
Heating Medium : Conduction Oil
Weight (kg) : 165
Package Size (mm) : 1500 X 800 X 1250 External Vibrator ZF55-50
Input : 380 V, 3~, 50 Hz
Rated Output (kW) : 0.55
Rated Current (A) : 1.2
Frequency (Hz) : 50
Vibration (rpm) : 3000
Amplitude (mm) : 5
Centrifugal Force (kN) : 5
Dimension (mm) : 310 X 220 X 190
Foot Dimension (mm) : 180 X 120
Foot Bolt : M16
Weight (kg) : 18Tamping Rammer Dragon TRD80H Honda GX160
Tipe Mesin Honda GX160 4-stroke, overhead valve 25° inclined, single cylinder, horizontal shaft Isi Silinder 163 cm³ Diameter x langkah 78.0 x 72 mm Rasio Kompresi 9.0 : 1 Tenaga Output Kotor (SAE J1995) (5.5HP)/3600rpm Impact energy 10 kN Impact Frequency 460 ~ 650 times/min Leap height 40 – 65 mm Tank Capacity 3,1 Liters Bottom Platesize 330 x 280 mm Nett Weight 75 kgs Gross Weight 99 kgs Dimension 750 x 500 x 1000 mm Steel Bar Cutter Everyday GQ46
Cutting Capacity (mm) : 6-42
Motor Power : 3.0KW-2P
Motor Speed (R/Min) : 2860
Cutting Speed (Cut/min) 48
Dimension (mm) 1100 X 500 X 900
Weight (kg) 470Vibratory Roller FYL-880
Walk Speed (km/h) : 0 – 5
Gradeability : 30% / ≤15o
Drive Type : Hydraulic Transmission
Vibration Control : Electro Cloutch
Vibration Frequency : 70 Hz
Exiting Force (kN) : 25
Water Tank (l) : 60
Hydraulic Oil Tank (l) : 19
Engine Model : Diesel
Power (hp) : 9
Starting Mode : Electric & Hand
Wheel Size Front (mm) : 540 X 740
Wheel Size Back (mm) : 540 X 800
Weight (kg) : 1000
Package Size (mm) : 2100 X 1000 X 1650 Portable Rebar Tier WL400
Battery Type : Ni-MH
Charger Voltage (V) : 110 – 240
Motor Voltage (V) : 9.6
Max. Tying Diameter (mm) : 25
Tying Intensity (kg) : 0.5
Wire Diameter (mm) : 0.8
Wire Length (cm) : 53 – 79
Weight (kg) : 2.1
Dimension (mm) : 277 X 100 X 290Internal Vibrator Wacker Neuson IE 58
Diameter of the vibrator head ⌀58mm Length of the vibrator head 327mm Weight of the vibrator head 1,5kg Protective hose 10 meter Operating weight 10,4kg Effective diameter 58cm Vibrations 12,000rpm Voltage 42V Current 12 Ampere Frequency 200Hz Power Cable 15meter -
Vibratory Roller FYL203H FURD
Walk Speed 0 – 8 km/h Gradeability 20 % Drive Type Mechanical Drive – Gearbox Vibration Control Electro Hydraulic Pump Vibration Frequency 50 Hz Exiting Force 32 kN Water Tank 200 Liters Hydraulic Tank 20 Liters Engine Model Diesel Changchai ZN390B Engine Power 26.5 Kw @2200rpm Starting Methode Electric Start Front Wheel Size ø 700 * 1090 mm Back Wheel Size ø 700 * 1090 mm Overall Dimension 2830 * 1290 * 2650 mm Overall Weight 3000 Kg Standards Compliance CE/ISO Vibratory Roller FYL-D203 FURD
Walk Speed 0 – 12 km/h Gradeability 30 % Drive Type Hydraulic Transmission Vibration Control Electro Hydraulic Pump Vibration Frequency 50 Hz Exiting Force 2 * 30 kN / 30 kN Water Tank 200 Liters Hydraulic Tank 80 Liters Engine Model Diesel Changchai ZN390B Engine Power 26.5 Kw @2200rpm Starting Methode Electric Start Front Wheel Size ø 700 * 1250 mm Back Wheel Size ø 700 * 1250 mm Overall Dimension 2760 * 1400 * 2580 mm Overall Weight 3000 ~ 3400 Kg Standards Compliance CE/ISO
Telescopic Boomlift Sinoboom GTBZ26
Platform height max 25.8 Meter Working Height Max 27.8 Meter Horizontal Reach Max. 22 Meter Ground Clearance 0.41 Meter Platform Size (L*W*H) 1.45 m* 0.85m* 1.24m Max. Platform Operator 2 Lift Capacity 250 ~ 480 Kg Turntable rotation 360° Platform rotation 160° Drive Speed 0~5.2 km/h Gradeability 30% Max. Noise on Normal Use 82 dB(A) Engine Brand Cummins Engine Power 60 Kw Overall Weight 16442 Kg Standards Compliance CE/ISO/ADR/ARAMCO Stamper Dynamic DTR85H Honda GX160
Engine Model : Honda GX160
Power (hp) : 5.5
Fuel Tank (l) : 2.0
Impact Force (kN) : 10
Impact Number : 450 – 650/min
Jumping Stroke (mm) : 40 – 60
Shoe Size (mm) : 330 X 290
Weight (kg) : 79
Dimension (mm) : 1080 X 420 X 760 Steel Bar Cutter Everyday GQ46
Cutting Capacity (mm) : 6-42
Motor Power : 3.0KW-2P
Motor Speed (R/Min) : 2860
Cutting Speed (Cut/min) 48
Dimension (mm) 1100 X 500 X 900
Weight (kg) 470Jack Hammer BH23 / BH55 Wacker Neuson
Engine Model : WM80 2-Stroke
Power (hp) : 2.18
Fuel Tank (l) : 1.8/
Displacement (cc) : 80
Impact Frequency (impact/min) : 1300
Impact Energy (J) : 55
Rotation Speed (rpm) : 4250
Weight (kg) : 24
Dimension (mm) : 777 x 492 x 346High Frequency Internal Vibrator HBM40VFLH Exen
Input 250W 48V 5,5A Frequency 200 Hz Total Length shaft + box +spear 4000 + 6000mm Diameter x Length 43 mm×360mm Weight 13,9 kg -
Asphalt Crack Sealing Machine FGF-60
Engine Model : Yamaha ET 950
Power : 760 W, 1 hp
Walking Mode : Hand Push
Material Tank Volume (l) : 60
Fuel Type : Liqufied Gas
Heating Medium : Conduction Oil
Weight (kg) : 165
Package Size (mm) : 1500 X 800 X 1250 External Vibrator ZF55-50
Input : 380 V, 3~, 50 Hz
Rated Output (kW) : 0.55
Rated Current (A) : 1.2
Frequency (Hz) : 50
Vibration (rpm) : 3000
Amplitude (mm) : 5
Centrifugal Force (kN) : 5
Dimension (mm) : 310 X 220 X 190
Foot Dimension (mm) : 180 X 120
Foot Bolt : M16
Weight (kg) : 18Handy External Vibrator Exen EKD EKCA
Input 280W 100V 5A Frequency 140 -200Hz Total Length 427mm Vibrating Face EKD 200x200mm
EKCA 120×150Weight EKD with Holder 7,6kg
EKCA with Holder 5,8Kg Mesin Serbaguna Honda GX 160 T2 (Thailand)
Tipe Mesin: Air cooled, 4-stroke, OHV , 25° inclined, single cylinder, horizontal shaft
Isi Silinder: 163 cm³
Diameter x langkah 68.0 x 45.0 mm
Rasio Kompresi 9.0 :1
Tenaga Output (5.5HP)/3600rpm
Kapasitas Tangki Bahan Bakar 3.1 Liters Gasoline Oktan 86 or higher
Sistem Pengapian Transistorized Magneto ignition
Tipe Busi BPR6ES, (NGK) W20EPR-U (DENSO)
Sistem Penyalaan Recoil starter
Pembersih Udara Semi dry type
Kapasitas Oli 0.58 Liters SAE 10W-30 (API SE or Later)
Dimensi 312 x 362 x 346 mm
Berat Kering 15 kg Mesin Serbaguna Honda GX 690 H
Tipe Mesin 4-stroke, overhead valve 90° V-twin cylinder Isi Silinder 688 cm³ Diameter x langkah 78.0 x 72 mm Rasio Kompresi 9.3 : 1 Tenaga Output Kotor (SAE J1995) 18.75kW (25.0HP)/3600rpm Tenaga Output Bersih (SAE J1349)* 16.5kW (22.1 HP)/3600 min-1 rpm Torsi Maksimum (SAE J1349)* 48.3 Nm (4.93 kgf-m)/2,500 rpm Kapasitas Tangki Bahan Bakar N/A, Unleaded Gasoline Oktan 86 or higher Konsumsi Bahan Bakar 6,7Liter/Hours Sistem Pengapian CDI type Magneto ignition Tipe Busi ZFR5F (NGK) Sistem Penyalaan Starter motor Pembersih Udara Dual element type Kapasitas Oli 1.5 Liters, 1.7 Liters (With oil filter replacement) SAE 10W-30 (API Service Class SE or later Dimensi 405 x 410 x 438 mm Diameter AS ØN/A Berat Kering 44,4 kg Tamping Rammer Dragon TRD80H Honda GX160
Tipe Mesin Honda GX160 4-stroke, overhead valve 25° inclined, single cylinder, horizontal shaft Isi Silinder 163 cm³ Diameter x langkah 78.0 x 72 mm Rasio Kompresi 9.0 : 1 Tenaga Output Kotor (SAE J1995) (5.5HP)/3600rpm Impact energy 10 kN Impact Frequency 460 ~ 650 times/min Leap height 40 – 65 mm Tank Capacity 3,1 Liters Bottom Platesize 330 x 280 mm Nett Weight 75 kgs Gross Weight 99 kgs Dimension 750 x 500 x 1000 mm Steel Bar Cutter Everyday GQ46
Cutting Capacity (mm) : 6-42
Motor Power : 3.0KW-2P
Motor Speed (R/Min) : 2860
Cutting Speed (Cut/min) 48
Dimension (mm) 1100 X 500 X 900
Weight (kg) 470
Produk Diskon
-
Jack Hammer BH23 / BH55 Wacker Neuson
Engine Model : WM80 2-Stroke
Power (hp) : 2.18
Fuel Tank (l) : 1.8/
Displacement (cc) : 80
Impact Frequency (impact/min) : 1300
Impact Energy (J) : 55
Rotation Speed (rpm) : 4250
Weight (kg) : 24
Dimension (mm) : 777 x 492 x 346High Frequency Internal Vibrator HBM40VFLH Exen
Input 250W 48V 5,5A Frequency 200 Hz Total Length shaft + box +spear 4000 + 6000mm Diameter x Length 43 mm×360mm Weight 13,9 kg High Frequency Internal Vibrator HBM60ZX Exen
Input 500W 48V 13,0A Frequency 200 Hz Total Length shaft + box 6350 mm Diameter x Length 61 mm×415mm Weight 17,5 kg High Frequency Internal Vibrator HBM50VF Exen
Input 400W 48V 9,0A Frequency 200 Hz Total Length shaft + box 6350 mm Diameter x Length 52 mm×397mm Weight 15,6 kg High Frequency Internal Vibrator HBM40VF Exen
Input 250W 48V 5,5A Frequency 200 Hz Total Length shaft + box 6350 mm Diameter x Length 43 mm×348mm Weight 11,8 kg
